PlastiFill PF-9000 SeriesIntegrated Plastic Resins Filling & Valve Bag Packaging System45 Bags/Min • ±0.3% Accuracy • Static-Free • ATEX/FDA Dual ComplianceTechnical SpecificationsParameterPF-9100
Integrated Plastic Resins Filling & Valve Bag Packaging System
45 Bags/Min ? ±0.3% Accuracy ? Static-Free ? ATEX/FDA Dual Compliance
| Parameter | PF-9100 (Standard) | PF-9200X (ATEX) | PF-9300F (Food-Grade) |
|---|---|---|---|
| Bag Capacity | 25-50kg (±0.3%) | 25-50kg (±0.35%) | 25-50kg (±0.25%) |
| Throughput | 45 Bags/Min | 40 Bags/Min | 40 Bags/Min |
| Resin Types | PP/PE/PVC/PS/ABS Pellets ? Powder ? Regrind | Same + Conductive Resins | FDA-Compliant Resins |
| Accuracy | ±0.3% Gravimetric | ±0.35% | ±0.25% |
| Filling Technology | Twin Screw Auger + Mass Flow Meter | ATEX Gear Pump | Servo Piston + Load Cells |
| Static Control | Ionized Air Curtain (10? ions/cm3) | Same + Grounded Path | Ultra-Low Static Auger |
| Dust Containment | -25Pa Hood + HEPA Filtration | Explosion-Proof Filter | CIP-Ready Enclosure |
| Material Contact | 304 SS (Ra<0.8μm) | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Valve Bag Handling | Auto-Centering Chuck ? Seal Integrity Check ? Auto-Reject | Same | Vision-Guided Placement |
| Changeover Time | <30s (Tool-Free) | <35s | <25s |
| Power | 480V/60Hz, 15kW | 24VDC Ex ia | 480V/60Hz, 12kW |
| Certifications | CE ? ISO 9001 | ATEX Zone 22 | FDA 21 CFR 177.1520 |
Performance Metrics:
| Resin Type | Static Voltage (Industry) | PF-9000 |
|---|---|---|
| PE Powder | >30kV | 0.8kV |
| PP Pellets | 15-25kV | 1.2kV |
| PS Regrind | 20-35kV | 0.5kV |
| Technology | Function | Accuracy |
|---|---|---|
| Mass Flow Meter | Real-Time Density Compensation | ±0.1% of Reading |
| Redundant Load Cells | Cross-Verification | ±0.05% Consistency |
| Auto-Bridging Prevention | Pulsed Vibration | 0% Flow Interruption |
Engineering Plastics
| Feature | Technology |
|---|---|
| Pellet Integrity | Low-Shear Auger (≤50 RPM) |
| Dust Generation | Cyclonic Separation + HEPA Filtration |
| Moisture Control | Dehumidified Air Flushing |
Food-Grade Polymers
FDA Compliance:
Contamination Defense:
| System | Specification |
|---|---|
| Metal Detection | >0.3mm Ferrous Particles |
| Air Filtration | ISO Class 7 Environment |
Conductive/Flame-Retardant Resins
| Component | ATEX Solution |
|---|---|
| Explosion Venting | 8m2 Rupture Panels |
| Spark Detection | IR Sensors + CO? Suppression |
| Static Dissipation | Surface Resistivity <10? Ω |
**10" HMI with ResinOS?**
AI-Driven Features:
Quality Sentinel:
| Parameter | Action |
|---|---|
| Melt Flow Variance >5% | Auto Auger Speed Adjustment |
| Pellet Fracture >2% | Vibration Reduction |
Preventive Maintenance:
| Component | Alert Threshold |
|---|---|
| Screw Wear | Torque >120% Baseline |
| Filter Saturation | ΔP >0.5 bar |
1. Valve Bag Auto-Loading → 2. Ionized Air Pre-Treatment → 3. Precision Filling (±0.3%) → 4. Dust-Free Spout Sealing → 5. 100% Weight/Metal Check → 6. Palletizing
Cycle Time: 1.3 seconds/bag
? ATEX 2014/34/EU Zone 22 (PF-9200X) ? FDA 21 CFR 177.1520 (PF-9300F) ? ISO 9001:2015 ? OIML R51 Gravimetric Standard
SABIC Saudi Arabia:
“After 6 months using PF-9100 for PP pellets:
Output: 1,800 → 2,700 bags/hour (+50%)
Material Loss: 1.8% → 0.25% ($420k/year saved)
Static-Related Stops: 12/day → 0
ROI: 5 months”
Resin Packaging Precision:
? Zero-Static Architecture: | **Technology**| **Performance**| |-------------------------|------------------------| | Ionized Air Curtain| 10? ions/cm3 Output| | Conductive Path| Surface Resistivity <10? Ω | | Humidity Control| 45% RH ±2%| ? Valve Bag Excellence: 1. Auto-Centering Chuck (±0.5mm) 2. Seal Integrity Sensor (99.99% Detection) 3. Reject Rate <0.05% ? Industry-Leading Efficiency: - 45 Bags/Minute Sustained - <30s Resin Changeover - 0.5% Residual Resin in Line
